Chevron Tile Laying Guide

Chevron Pattern Overview:

The chevron structure makes a stunning and dynamic V-shaped zigzag pattern with precisely curved edge tiles. Unlike regular herringbone, chevron tiles' ends are curved at an angle, allowing them to fit together effortlessly and produce a continuous arrow-like pattern.

Tile Size and Shape:

• Each tile measures 450 mm long and 80 mm wide.
• To complete the pattern, the angled tiles come in LEFT and RIGHT types
• The effective width coverage per set is 1150 mm (two 450 mm tiles arranged at an angle)

Laying Instructions:

1. Start from the Center:
Start laying at the center point where the V-shape meets. This creates a symmetrical and balanced layout.

2. Align Left and Right Tiles:
Use the LEFT and RIGHT tiles alternately.
To form a seamless chevron V-shape, ensure that their angled ends meet exactly.

3. Spacing:
Maintain a minimum 2 mm grout joint between tiles.
Accurate spacing is critical for creating a clean, professional appearance.

4. Continue Outwards:
Continue laying tiles in both directions to extend the pattern evenly.
Use level guides and spacers to keep straight lines and angles.
